22KW 32A Electric Vehicle Battery Charging Station Type1 Type2 GB/T AC EV Charging Pile New Energy EV Portable Car Charger
BeiHai Power 22KW 32A Electric Vehicle Charging Station–Powerful, multi-interface, portable and easy to use, intelligent and safe EV Charger
The 22KW 32A Electric Vehicle Charging Station is a state-of-the-art solution designed to meet the evolving needs of electric vehicle (EV) owners. With its versatile charging capabilities, this unit supports Type 1, Type 2, and GB/T connectors, ensuring broad compatibility across different vehicle brands and models. Engineered for both home and public use, this AC charging pile is ideal for those seeking a high-performance, fast, and reliable charging solution.
Featuring a compact and portable design, it is perfect for both residential and commercial applications, allowing EV owners to quickly and efficiently charge their vehicles. The 22KW power output ensures fast charging times, while its advanced safety features guarantee the protection of both the vehicle and the charging equipment.
Whether you’re looking to charge at home or need a mobile charging solution on the go, this charging station offers convenience, reliability, and high-efficiency performance. Its smart features and high-quality build make it a trusted choice for EV owners committed to sustainable, green travel.
Product Parameters
| Model | BHPC-022 |
| AC Power Output Rating | Max 24KW |
| AC Power Input Rating | AC 110V~240V |
| Current Output | 16A/32A(Single-Phase,) |
| Power Wiring | 3 Wires-L1, PE, N |
| Connector Type | SAE J1772 / IEC 62196-2/GB/T |
| Charging Cable | TPU 5m |
| EMC Compliance | EN IEC 61851-21-2: 2021 |
| Ground Fault Detection | 20 mA CCID with auto retry |
| Ingress Protection | IP67,IK10 |
| Electrical Protection | Over current protection |
| Short circuit protection | |
| Under voltage protection | |
| Leakage protection | |
| Over temperature protection | |
| Lightning protection | |
| RCD type | TypeA AC 30mA + DC 6mA |
| Operating Temperature | -25ºC ~+55ºC |
| Operating Humidity | 0-95% non-condensing |
| Certifications | CE/TUV/RoHS |
| LCD Display | Yes |
| LED Indicator Light | Yes |
| Button On/OFF | Yes |
| External Package | Customizable/Eco-Friendly Cartons |
| Package Dimension | 400*380*80mm |
| Gross Weight | 5KG |
FAQ
What is your terms of payment?
A:L/C, T/T, D/P, Western Union, Paypal, Money Gram
Do you test all your chargers before shipping?
A: All major components are tested before assembly and each charger is fully tested before shipped
Can I order some samples? How long?
A: Yes, and usually 7-10 days to production and 7-10 days to express.
How long to fully charge a car?
A: To know how long to charge a car, you need to know the OBC(on board charger) power of the car, the car battery capacity, the charger power. The hours to fully charge a car =battery kw.h/obc or charger power the lower one. For e.g, the battery is 40kw.h, obc is 7kw, charger is 22kw, the 40/7=5.7hours. If the obc is 22kw, then 40/22=1.8hours.
Are you Trading Company or manufacturer?
A: We are professional EV charger manufacturer.
Why Choose This 22KW 32A EV Charging Station?
A: This charging station is designed with the modern EV owner in mind, offering a perfect balance of speed, safety, and ease of use. Its universal compatibility, fast charging times, and high-tech safety measures make it an indispensable tool for anyone looking to make the most of their electric vehicle.
-
